AMC-262

AMC-262, 6-Slot Wallmount Chassis, Full-Size/ Half-Size Cards Support

SKU: ETE970187 Category:

Download PDF

Description

Overview

The 6-slot AMC-262 wallmount chassis sports one 5.25″ and one 3.5″ external drive bays, two internal drive bays, and support for the standard PS2 power supply.

Applications

  • Industrial Automation
  • Factory Automation
  • Control Box
  • Banking machine
  • ITS/ Transportation
  • HMI
  • Workstation

Features

  • 6-Slot Wallmount Chassis
  • 6-Slot ISA/ PICMG Bus Passive Backplanes
  • Standard PS2 Power Supply
  • External 3.5” Drive Bay x 1
  • External 5.25” Drive Bay x 1
  • Internal 3.5” Drive Bay x 2
  • USB2.0 x 2 On Front Panel

Specifications [AMC-262]

system
Construction Heavy-duty steel
Front Panel Power ON/OFF Switch x 1 Reset Button x 1
Power LED x 1 HDD Active LED x 1
PS/2 Keyboard Connector x 1 USB Port x 2
Rear Panel Reserved Cut-out for DB-25 Connector x 1 Reserved Cut-out for DB-9 Connector x 1
6 slots (including system slot), supports max. 339 mm (length) for expansion card
Color White
Dimension (W x D x H) 6.9″ (W) x 16.1″ (D) x 10″ (H) (175mm x 405mm x 254mm)
Carton Dimension 12.4″ (W) x 14.37″ (D) x 20.47″ (H) (315mm x 365mm x 520mm)
Net Weight 12.1 lb (5.5 kg)
Gross Weight 13.9 lb (6.3 kg)
Storage External: 3.5” Drive Bay x 1
5.25” Drive Bay x 1
Internal: 3.5” Drive Bay x 2
System Fan 12cm Ball Bearing Fan with Removable Filter x 1
environmental
Operating Temperature 32°F ~ 122°F (0°C ~ 50°C)
Storage Temperature -4°F ~ 176°F (-20°C ~ 80°C)
Storage Humidity 10 ~ 80% @ 40°C, non-condensing
Vibration 0.5 Grms/ 5 ~ 500Hz/ operation
1.5 Grms/ 5 ~ 500Hz/ non operation
SHOCK 15 G peak acceleration (11 m sec. duration), operation
30 G peak acceleration (11 m sec. duration), non operation
EMC CE/FCC Class A

Ordering Information [AMC-262]

Part Number TF-AMC-262-W-00
description Wallmount, 6-Slot Bare Chassis, for PS2 Power, PS_SW (ATX), Color: White

Optional Accessories

Power Supply Options

P/N TYPE PFC Support Input Voltage Watt Size
1255304003 ATX Active PFC Auto 90 ~ 264V 400W PS2

Passive Backplane Options

P/N Description Master Interface Slots Power Connector, ATX Extend Function
BP-206SP-P4 Wallmount, PCI, 6-Slot Backplane, 4 PCI, Single Segment, ATX PCI 4/0/2 (PCI/ ISA/ PICMG_PCI) ATX, 3-pin ATX extend
BP-206SS-P4 Wallmount, PCISA, 6-Slot Backplane, 4 PCI, 3 PCISA, Single Segment, ATX PCISA 4/1/0 (PCI/ ISA/ APCI) ATX
BP-206SG-P2 Wallmount, PICMG, 6-Slot Backplane, 2 PCI, 3 ISA, Single Segment, ATX PICMG 1.0 2/3/1 (PCI/ ISA/ PICMG) ATX, 3-pin ATX extend
BP-206SG-P4 Wallmount, PICMG, 6-Slot Backplane, 4 PCI, 2 ISA, Single Segment, ATX PICMG 1.0 4/2/2 (PCI/ ISA/ PICMG) AT, ATX, 3-pin ATX extend
BP-206SH-P3 Wallmount, Backplane, PICMG 1.3, 6-Slot, 3 PCI, 2 PCI-E, Single segment, ATX PICMG 1.3 3/2/1 (PCI/PCI-E/PICMG 1.3) ATX
BP-206SI Wallmount, ISA 6-Slot Backplane, 6 ISA, Single segment, AT/ATX ISA (0/6/0) AT/ATX

CPU Cards Options

Model/Name Description Master Interface
FSB-G41H Socket LGA 775, Intel® Core™ 2 Duo/ Core™ 2 Quad (800/1066/1333) PICMG 1.3
FSB-B75G Socket LGA 1155, Intel® 3rd Generation i3/i5/i7 PICMG 1.0
HSB-800I Onboard AMD LX 800 Processor ISA

CPU Cooler Options

Model/Name Description
1759218000 LGA1155/1150 CPU Cooler (1.5U)
175920000G LGA775 CPU Cooler (1U)
1759200335 LGA775 CPU Cooler (1U)
