Description
The BOXER-6845-BTL is an Expansion Box PC powered by up to 65W CPUs from the Intel Core Processor Series 2 range (formerly Bartlett Lake), including SKUs with a dedicated performance-core architecture. At 150 x 270 x 225 mm it is 43% smaller than its predecessor, bringing high-performance computing to space-constrained settings such as cabinets and mobile robotic units, and is available in both fan-assisted and fanless models.
It supports GPUs with power requirements up to 150W, enabling it to leverage cards such as the 770 TOPS NVIDIA RTX PRO 4000 Blackwell SFF Edition for heavy edge AI inference. Two SKUs are offered: the A1 model uses a PCIe x16 + PCIe x4 riser for powerful GPUs, while the A2 model offers a PCIe x4 + PCI configuration for legacy cards like motion controllers, frame grabbers and industrial communication cards. Storage includes two 2.5 inch SATA bays with RAID 0/1 plus two M.2 2280 M-Key NVMe slots. I/O comprises three lockable RJ-45 LAN ports, two USB 3.2 (10 Gbps) ports, two DB-9 ports for RS-232/422/485 and a DB-15 port for 8-bit digital I/O, with Wi-Fi and 5G expansion via M.2 E-Key and B-Key slots and a front-access Nano SIM slot.
